BƠM NƯỚC ISUZU 4BD1 - PHỤ TÙNG XE ĐÀO HITACHI EX120-2

Mã chi tiết sản phẩm phụ tùng động cơ Isuzu 4BD1-TPZ02 dùng cho xe đào Hitachi EX120-2.

Ngày đăng: 07-08-2019

510 lượt xem

Mã chi tiết sản phẩm phụ tùng động cơ Isuzu 4BD1-TPZ02 dùng cho xe đào Hitachi EX120-2.

№	Part number	Part name	Serial
1	8943768431	PUMP ASM; WATER,W/GASKET	199311 - 199506
1	8972511841	PUMP ASM; WATER,W/GASKET	199507 -
3	9136140440	GASKET; PUMP TO C/BL	199311 -
4	8943809471	REPAIR KIT; WATER PUMP	199311 -
7(A)	5136630302	PULLEY; WATER PUMP	199311 -
9	9091801470	RING; SNAP,WATER PUMP	199311 -
11	5136320010	SPACER; BRG,WATER PUMP	199311 -
16	5096250780	SEAL; OIL,WATER PUMP	199311 -
18	5136210110	IMPELLER; WATER PUMP	199311 -
19	5136130070	GASKET; COVER TO BODY	199311 -
20	5136120100	COVER; WATER PUMP	199311 -
25	5136420530	CENTER; WATER PUMP	199311 -
26(A)	5136390020	COVER; DUST,WATER PUMP	199311 -
27	5098000520	BEARING; WATER PUMP	199605 -
27	5098000520	BEARING; WATER PUMP	199311 - 199604
28(A)	5095030990	WASHER; WATER PUMP	199311 -
29	8943777860	SHAFT; WATER PUMP	199311 -
30	9099521030	RING; SNAP,WATER PUMP SHAFT	199311 -
31	8943299120	PIPE; SUCTION,INL	199507 -
32	5136200062	SEAL UNIT; WATER PUMP	199311 - 200003
32	1136200240	SEAL UNIT; WATER PUMP	200004 -
34	9030908200	SCREW; COVER TO BODY,WATER PUMP	199311 -
36	500410350	BOLT; WATER PUMP TO C/BL	199311 -
36	500410500	BOLT; WATER PUMP TO C/BL	199311 -
36	5090300101	BOLT; WATER PUMP TO C/BL	199311 -
39	5136390070	SLINGER	199311 -
